Efficient Complet 150L Cheese Production Line For sale
1.Complet 150L Cheese Production Line Product introduction:
Yogurt and Cheese Production Line is consisted of these following machines:
1: Receiving Tank, this is used to receive raw material
2: Cooling Tank. Used to Storage
3:Preheating Tank: used to heat the milk pumped from storage tank so that it take less time when it is homogenized.
4:Homogenizer: This machine causes a series of changes in the material, chemistry, and structural nature of the material, and finally achieves the effect of the average quality
5: Pasteurization and Fermentation Tank: used to sterilize the milk , can get the pasteurized milk or can pump the milk into the fermentation tank
6:Cheese Tank : for curdling/cutting
7:molding: to form cheese.
7:Pump:used to transfer the milk from one tank to another
8:pipes, valves etc,filter: used to connect the machines
Related Machines:
Receiving tank-refrigeration tank - milk pump - pipeline filtration - preheating tank - milk pump - homogenizer - sterilization tank - milk pump - cheese tank - forming tank
2.Technical parameters:
|
1 |
|
|
150L receiving tank |
|
|
Material |
304 stainless steel |
|
Volume |
150L |
|
Plate thickness |
1.5mm |
|
Tank diameter |
630mm |
|
Height inside the tank |
600mm |
|
2 |
|
|
Single pipeline filtration |
|
|
Material |
304 stainless steell |
|
Filter screen |
100 mesh |
|
Capacity |
1000L/hour |
|
3 |
|
|
150L refrigeration tank |
|
|
Overall dimensions |
1350*1000*1220mm |
|
Unit power |
3P |
|
Total power |
2kw |
|
Refrigerating working fluid |
R22 |
|
Thermal insulation performance |
≤1℃/3h |
|
Mixer speed |
36r/min |
|
Mixing power |
0.37kw |
|
Voltage |
380V/50hz |
|
Material |
304 stainless steel |
|
4 |
|
|
150L preheating tank |
|
|
Equipment size |
900*750*1370mm |
|
Tank diameter |
625mm |
|
Tank height |
620mm |
|
yield |
10-150kg/time |
|
Heating cycle |
25-35min |
|
Material |
304 stainless steel |
|
Voltage |
380V/50hz |
|
power |
6kw |
|
5 |
|
|
500L homogenizer |
|
|
Capacity |
500L/h |
|
Maximum pressure |
25mpa |
|
working pressure |
20mpa |
|
Motor power |
4kw |
|
Overall dimensions |
1010*616*975 |
|
Voltage |
380V/50hz |
|
Material |
304 stainless steel |
|
6 |
|
|
150L sterilization tank |
|
|
Equipment size |
900*750*1370mm |
|
Tank diameter |
625mm |
|
Tank height |
620mm |
|
Capacity |
10-150kg/time |
|
Heating cycle |
25-35min |
|
Sterilization temperature |
40-90℃ |
|
Material |
304 stainless steel |
|
Voltage |
380V/50hz |
|
Power |
9kw |
|
7 |
|
|
150L fermentation tank |
|
|
Equipment size |
900*750*1370mm |
|
Tank diameter |
625mm |
|
Tank height |
620mm |
|
yield |
10-150kg/time |
|
Fermentation temperature |
40-60℃ |
|
fermentation time |
0-999min |
|
Material |
304 stainless steel |
|
Voltage |
380V/50hz |
|
Power |
9kw |
|
8 |
|
|
300L cheese can |
|
|
Capacity |
300L |
|
Material |
304 stainless steel |
|
Plate thickness |
2mm |
|
power |
380V/18kw |
|
Equipment size |
1250*1000*1700mm |
|
Tank diameter |
900mm |
|
Tank height |
650mm |
|
Mixing speed |
Variable frequency stirring |
|
Mixing motor power |
0.55kw |
|
Material import and export |
DN38 |
|
9 |
|
|
Cheese forming tank |
|
|
Model |
HT-CXJ950 |
|
Dimensions |
950*950*1360mm |
|
Dimensions inside the forming box |
450*350*85mm |
Contact Us to Get a Quote
3.Complet 150L Cheese Production Line pictures:
 |
 |
 |
 |
 |
 |
